GN Pan 手推车系列（380-740 毫米 / 16-32 Pan）

This GN pan trolley series includes standard trolley models and high-capacity 16-pan and 32-pan models, with widths from 380 mm to 740 mm and heights from 1000 mm to 1735 mm. All units feature 304-grade stainless steel top and bottom shelves, 30 × 30 × 1.0 mm and 25 × 25 × 1.0 mm stainless steel frame construction, and 4-inch swivel silent casters for bakeries, hotel pastry kitchens, and central kitchens.

    申请报价

    请输入您的电子邮件地址，我们将尽快给您回复。

    分类： 品牌：

    This GN pan trolley series is designed for storing, transporting, and organizing baking trays, GN pans, sheet pans, and other food preparation containers in bakeries, hotel pastry kitchens, central kitchens, canteens, catering operations, and commercial food production areas. The trolleys help bakers and kitchen staff move multiple pans efficiently between workstations, ovens, coolers, and storage areas.

    The series includes standard GN pan trolley models and high-capacity pan trolley models with 16-pan and 32-pan configurations. The standard models are suitable for general kitchen tray handling, while the high-capacity models are designed for larger-scale baking and food preparation operations. Product widths range from 380 mm to 740 mm, and heights from 1000 mm to 1735 mm, allowing users to select the appropriate trolley according to available space and volume requirements.

    All models feature a top and bottom shelf made from 304-grade stainless steel plate. The main frame is constructed from 30 × 30 × 1.0 mm stainless steel square tubes, and the secondary frame uses 25 × 25 × 1.0 mm stainless steel square tubes. Each trolley is equipped with 4-inch high-quality swivel silent casters for smooth and quiet movement. Overall manufacturing tolerance is ±5 mm.

    产品特点

    • Designed for storing and transporting baking trays, GN pans, sheet pans, and food preparation containers.
    • Available in standard GN trolley models and high-capacity 16-pan and 32-pan trolley models.
    • Width options range from 380 mm to 740 mm, height options include 1000 mm and 1735 mm.
    • Top and bottom shelves made from 304-grade stainless steel plate.
    • Main frame uses 30 × 30 × 1.0 mm stainless steel square tubes.
    • Secondary frame uses 25 × 25 × 1.0 mm stainless steel square tubes.
    • Equipped with 4-inch high-quality swivel silent casters.
    • 制造公差为 ±5 毫米。

    应用领域

    Suitable for bakeries, hotel pastry kitchens, central kitchens, canteens, catering kitchens, school kitchens, factory dining halls, and commercial food production areas that require mobile pan storage and transport equipment.

    型号 产品名称 手推车类型 产品尺寸
    HYL-CK-SS-C01 Standard GN Pan Trolley Standard GN pan trolley 380 × 550 × 1000 mm
    HYL-CK-SS-C02 Standard GN Pan Trolley Standard GN pan trolley 380 × 550 × 1735 mm
    HYL-CK-SS-C03 32-Pan GN Pan Trolley 32-pan high-capacity trolley 470 × 620 × 1735 mm
    HYL-CK-SS-C04 16-Pan GN Pan Trolley 16-pan high-capacity trolley 670 × 820 × 1735 mm
    HYL-CK-SS-C05 Standard GN Pan Trolley Standard GN pan trolley 740 × 550 × 1000 mm
    HYL-CK-SS-C06 Standard GN Pan Trolley Standard GN pan trolley 740 × 550 × 1735 mm

    技术配置

    配置项目 系列详情
    Trolley Application Storing and transporting baking trays, GN pans, sheet pans, and food preparation containers
    手推车类型选项 Standard GN pan trolley and high-capacity 16-pan and 32-pan models are available
    主框架材料 30 × 30 × 1.0 mm 304-grade stainless steel square tube
    Secondary Frame Material 25 × 25 × 1.0 mm 304-grade stainless steel square tube
    货架材料 Top and bottom shelves made from 304-grade stainless steel plate
    Caster Type 4-inch high-quality swivel silent casters
    制造公差 ±5毫米
