集成式面盆龙头（H59 黄铜）

This integrated sink basin faucet is designed for bar stations, beverage preparation areas, coffee counters, and compact commercial kitchen spaces where a combined sink basin and water faucet in one unit is required. It provides a dedicated water point for glass rinsing, small utensil washing, and handwashing in a compact footprint.

The unit is a deck-mount design that combines a sink basin and a single-temperature faucet into one assembly. Both the sink basin and the faucet body are cast from H59 brass and finished with polished chrome plating, providing a durable, corrosion-resistant, and professional appearance suitable for daily commercial use.

The water supply inlet pipe accepts 1/2 inch or 5/16 inch connections, and the drain outlet uses a 1 1/4 inch pipe connection. The sink basin requires a 175 mm diameter cutout for installation, while the faucet mounting hole requires a 1 inch diameter opening. This compact integrated design simplifies installation and provides a clean, streamlined look for front-of-house beverage stations.

产品特点

• Integrated sink basin and faucet in one deck-mount unit.
• Both sink basin and faucet cast from H59 brass with polished chrome plating.
• Suitable for glass rinsing, handwashing, and small utensil cleaning.
• Water inlet supports 1/2 inch or 5/16 inch pipe connection.
• Drain outlet uses 1 1/4 inch pipe connection.
• Sink basin cutout diameter is 175 mm; faucet mounting hole is 1 inch.
• Compact design ideal for bar counters and beverage stations.

应用领域

Suitable for bar counters, beverage preparation areas, coffee shop stations, hotel bar sinks, restaurant service areas, and commercial kitchen spaces where a compact integrated sink and faucet solution is required.
